CDLF

[cdlf] s.s.304 vertical multicelulares Pump Stainless Steel Centrifugal PUMP

CDL / cdlf es un producto multifuncional que se puede utilizar para transportar todo tipo de medios de agua del grifo a líquidos industriales.
Bajo diferentes temperaturas, diferentes caudales y presiones.El tipo CDL es adecuado para el transporte de líquidos no corrosivos.
Cdlf es adecuado para líquidos ligeramente corrosivos.

Líquido Delgado, limpio, no inflamable, no explosivo, libre de partículas sólidas y fibras.
●Temperatura del líquido:
Tipo de temperatura normal: - l5c ~ + 70c,
Tipo de agua caliente: - 15C ~ + 120c
●Temperatura ambiente: hasta + 40℃.
●Altitud: hasta 1000 metros
3D PRODUCT CHAT NOW



CDL/ CDLF is a kind of multifunctional products.It can be used to convey various medium from tap waterto

industrial liquid at different temperature and with di-fferent flow rate and pressure. CDL type is applicable

toconveying non-corrosive liquid, while CDLF is suitablefor slightly corrosive liquid.
●Water supply: Water filter and transport in Waterworks, boosting of main pipeline, boosting in high-rise

buildings.
●Industrial boosting: Process flow water system, cleaning system, high-pressure washing system, fire

fightingsystem.
●Industrial liquid conveying: Cooling and air-conditioning system, boiler water supply and condensing

system,.machine-associated purpose, acids and alkali.
●Water treatment: Ultrafiltration system, reverse osmosis system, istillation system, separator, swimming pool.
●Irrigation: Farmland irgation, spray irrigation, dripping irrigation.

Thin, clean, non-flammable and non-explosive liquidcontaining no solid granules and fibers.
●Liquid temperature:
Normal temperature type: -l5C ~+70'C,
Hot water type:-15C~+120C
●Ambient temperature: up to +40C.
●Altitude:up to 1000m
●Full-enclosed air -blast two-pole standard motor
●Protection class: 1P55
●Insulation class: F
●Standard voltage:50Hz: 1 x 220-230/ 240V
3 x 200-220/ 346-380V
3 x 220-240/ 380-415V
3 x 380-415V

Other sizes can be on the request.

Purity Pump Co., Ltd. is a specialized manufacturer and supplier of high-quality

industrial pumps, exporting to global market in competitive prices. We provide

variousreliable pumps for projects.Our main products are centrifugal pumps, fire

pumps and system, industrial pumps and agricultural pumps.


Our products and services have been deployed in more than 55 countries.

And we supply water pumps for many large projects like National Olympic Stadium.

We also supply centrifugal and fire pumps to some well-known pump companies all

over the world.





CDL/ CDLF is a kind of multifunctional products.It can be used to convey various medium from tap waterto

industrial liquid at different temperature and with di-fferent flow rate and pressure. CDL type is applicable

toconveying non-corrosive liquid, while CDLF is suitablefor slightly corrosive liquid.
●Water supply: Water filter and transport in Waterworks, boosting of main pipeline, boosting in high-rise

buildings.
●Industrial boosting: Process flow water system, cleaning system, high-pressure washing system, fire

fightingsystem.
●Industrial liquid conveying: Cooling and air-conditioning system, boiler water supply and condensing

system,.machine-associated purpose, acids and alkali.
●Water treatment: Ultrafiltration system, reverse osmosis system, istillation system, separator, swimming pool.
●Irrigation: Farmland irgation, spray irrigation, dripping irrigation.

Thin, clean, non-flammable and non-explosive liquidcontaining no solid granules and fibers.
●Liquid temperature:
Normal temperature type: -l5C ~+70'C,
Hot water type:-15C~+120C
●Ambient temperature: up to +40C.
●Altitude:up to 1000m
●Full-enclosed air -blast two-pole standard motor
●Protection class: 1P55
●Insulation class: F
●Standard voltage:50Hz: 1 x 220-230/ 240V
3 x 200-220/ 346-380V
3 x 220-240/ 380-415V
3 x 380-415V

Purity Pump Co., Ltd. is a specialized manufacturer and supplier of high-quality

industrial pumps, exporting to global market in competitive prices. We provide

variousreliable pumps for projects.Our main products are centrifugal pumps, fire

pumps and system, industrial pumps and agricultural pumps.


Our products and services have been deployed in more than 55 countries.

And we supply water pumps for many large projects like National Olympic Stadium.

We also supply centrifugal and fire pumps to some well-known pump companies all

over the world.
