Descripción técnica
Nueva bomba estándar de acero inoxidable
Diseño original puro
• motores cuadrados y circulares disponibles
Motor de alta eficiencia ye3, clase de protección ip55 F
Carcasa de bomba Aisi 304 de acero inoxidable
Impulsor de acero inoxidable Aisi 304
Eje de acero inoxidable Aisi 304
Rodamientos NSK de alta calidad, sellos mecánicos resistentes al desgaste
3D PRODUCT CHAT NOW


NEW/NUEVO


TECHNICAL DESCRIPTION
· New stainless steel standard pump
· Original design by PURITY
· Both square motor & round motor available
· YE3 high efficient motor, with protection IP55 class F
· Pump case in stainless steel AISI 304
· Impeller in stainless steel AISI 304
· Shaft in stainless steel AISI 304
· Quality NSK bearing, wear resistance mechanical seal


USING LIMITS
· Liquid temperature between -10℃ and +120℃
· Ambient temperature up to +50℃
· Max. working pressure 16 bar
· Continuous service S1



APPLICATIONS
· Used for: water supply, cleaning sets, pressure boosting, firefighting sets, irrigation, industrial applications, water circulation in climatisation sets, agricultural applications.
· Suitable for use with clean, aggressive liquids that are chemically compatible with the materials from which the pump is made.
· The pumps must be installed in enclosed places, or at least protected against inclement weather.




NEW/NUEVO


TECHNICAL DESCRIPTION
· New stainless steel standard pump
· Original design by PURITY
· Both square motor & round motor available
· YE3 high efficient motor, with protection IP55 class F
· Pump case in stainless steel AISI 304
· Impeller in stainless steel AISI 304
· Shaft in stainless steel AISI 304
· Quality NSK bearing, wear resistance mechanical seal


USING LIMITS
· Liquid temperature between -10℃ and +120℃
· Ambient temperature up to +50℃
· Max. working pressure 16 bar
· Continuous service S1

APPLICATIONS
· Used for: water supply, cleaning sets, pressure boosting, firefighting sets, irrigation, industrial applications, water circulation in climatisation sets, agricultural applications.
· Suitable for use with clean, aggressive liquids that are chemically compatible with the materials from which the pump is made.
· The pumps must be installed in enclosed places, or at least protected against inclement weather.
